PM865K01 working control mode:
Work through stored program cycles.
I/O manipulation method: adopting batch processing method, that is, when executing the END instruction.
I/O instructions can be rewritten.
PM865K01 Work processing time:
Root instruction: 0.8 μ s/instruction.
Application instructions: 1.52 to several hundred μ s/instruction.
PM865K01 programming language:
Supports logical ladder diagrams and instruction lists.
The use of step ladder diagrams can generate SFC type programs.
PM865K01 Program Capacity:
Built in 8000 steps.
The use of additional storage boxes can be expanded to 16000 steps.
PM865K01 Instruction count:
Fundamental order instructions: 27.
Step ladder command: 2.
Application instructions: 128, a total of 298 available application instructions.
PM865K01 I/O equipment:
Hardware I/O equipment points: 256 points (depending on user selection, software can set address input 256 and output 256).
Auxiliary relay (M coil): generally 500 points (M0 to M499); Determine 2572 points (M500 to M3071); Special 256 points (M8000 to M8255).
Condition relay (S coil): generally 490 points (S0 to S499); Determine 400 points (S500 to S899); Initial 10 points (S0 to S9); Signal 100 points (S900 to S999).
Timer (T): Multiple types, including 100 milliseconds, 10 milliseconds, 1 millisecond hold type, etc., totaling 255 points.
Counter (C): Generally 16 bits, with a scale of 0 to 32767, totaling 200 points (C0 to C199).
Communication interface:
Having multiple communication interfaces, such as Ethernet, serial communication, etc., for data exchange with other devices and systems.
PM865K01 Hardware specifications:
It includes a 96MHz processor and 32MB of memory, ensuring its high performance and fast data processing capabilities.
Redundancy:
Some modules support redundant configuration to improve system reliability and fault tolerance.
Security:
has safety functions and can be used for safety critical applications such as emergency shutdown and fault detection.
PM865K01 Specification:
Product net depth/length: 135 mm.
Net height of the product: 186 mm.
Net width of the product: 119 mm.
Net weight of the product: 1.2 kg.
External connections include:
Excitation current to load sensor
2 or 4 analog input ports for load sensor signals
4 analog output ports (voltage or current)
8 digital input ports for controlling signals
8 digital output ports
+24V power supply, maximum 0.5A
Ethernet connection
Services and multiple control units
Two serial interface types.
