3500/50 Function Overview:
Speed monitoring: designed to monitor the speed of rotating mechanical equipment, such as engines, turbines, pumps, and fans. It can accurately measure the rotational speed of the rotor and feedback this data to the control system.
Vibration monitoring: In addition to speed monitoring, this module can also monitor the vibration situation of mechanical equipment, thereby helping users detect equipment faults and abnormal operating conditions early and take preventive maintenance measures.
Mechanical protection: With mechanical protection function, it can issue an alarm in case of abnormal vibration or speed problems of the equipment, and take corresponding protective measures to prevent equipment damage or shutdown.
3500/50 technical parameters:
Input signal: Accepts input from proximity probes or magnetic sensors to determine shaft speed, rotor acceleration, or rotor direction.
Input impedance: Depending on the type of sensor, the input impedance is 20 k Ω (standard), 40 k Ω (TMR), and 7.15 k Ω (internal potential barrier), respectively.
Power consumption: The typical value is 5.8 watts.
Output impedance: 550 Ω.
3500/50 Programming and Configuration:
Programming software: Use 3500 rack configuration software for programming.
Configuration options:
Speed monitoring, set point alarm, and speed range alarm
Speed monitoring, set point alarm, and zero speed notification
Speed monitoring, set point alarm, and rotor acceleration alarm
Speed monitoring, set point alarm, and reverse rotation notification
3500/50 Features:
Dual channel design: as a dual channel module, it can simultaneously process input signals from two different sensors, improving the accuracy and reliability of monitoring.
Peak holding function: With peak holding function, it can store the highest speed that the machine has reached, making it convenient for users to conduct subsequent analysis and comparison.
User programmable alarm: Users can set alarm thresholds according to actual needs. When the speed or vibration exceeds the set value, the module will issue an alarm to remind users to pay attention.
3500/50 application scenarios:
Industrial field: widely used in key equipment monitoring in industries such as petrochemicals, electricity, steel, and papermaking, ensuring the normal operation of equipment and timely detection of potential faults.
Preventive maintenance: By monitoring the speed and vibration of the equipment in real-time, users can detect equipment abnormalities in advance and carry out preventive maintenance, reducing failure rates and downtime.
