3500/22M technical specifications:
Input signal: -10 Vdc to+10 Vdc
Power consumption: 7.7 watts
Axis power supply and sensor power supply: -24 Vdc
Temperature: 25 degrees Celsius
Weight: 0.85 pounds (or 0.91kg according to another source)
Dimensions: 9.50 x 4.50 x 1.00 inches (or 241.3mm x 24.4mm x 241.8mm depending on another source)
3500/22M functional features:
Data interface: serves as a bridge between the 3500 monitoring system and compatible software (such as System 1 status monitoring and diagnostic software and 3500 system configuration software).
Data collection: Interact with M-series monitors (such as 3500/40M, 3500/42M, etc.) to collect steady-state and transient dynamic (waveform) data.
Optional feature: Use an optional channel enable disk to record dynamic, high-resolution transient data.
Location: In a 3500 rack, typically located in a slot next to the power supply.
3500/22M application areas:
Electricity: used to monitor the operation status of rotating equipment, such as motors, generators, etc.
Petrochemical: Monitoring parameters such as temperature and pressure in continuous production processes such as petrochemicals.
Manufacturing: Used for monitoring and controlling various parameters in manufacturing industries such as chemical, pharmaceutical, and food processing.
